| 除濕枯燥送料組合 |
TCD 編空調排濕氣繁瑣上料功能結構及空調排濕氣、繁瑣、二段上料功能兩種的功效于三合一，多見共用于各大pppp塑料材料，有點是吸水性較少的建設項目pppp塑料，如 PA、PC、PBT、PET 等，TCD-H 型在報負現狀分析也評均能夠達到 -40℃的露點，該編品去尊重 TD-H 編蜂巢轉輪空調排濕氣機配技巧下吹式全不銹鋼304歐化隔熱繁瑣料桶結構而成。全編去尊重 P.l.D 控溫體制為規范性設置成設施罷放，另實現供應者充足 PLC 規范配技巧 LCD 觸控式組排對話框供選用，實現供應者充足露點計和會去主動塑料填料機供選用。
TCD series dehumidification drying combined feeding and dehumidification, drying, 2 feed three functions in one, is widely used in all kinds of plastic raw materials, especially the hygroscopicity strong engineering plastics, such as PA, PC, PBT, PET, TCD - H in the ideal state is the lowest of dew point to 40 ℃, This series of products is made of TD-H series honeycomb transmission dehumidifier com?bined with down-blown all stainless steel European thermal insulation drying drum. The whole series adopts the P.l.D temperature control system as the standard accessories, and also provides PLC control with LCD touch man-machine interface for optional selec?tion, dew point meter and automatic filler for optional selection.
TCD 除潮死板組合成一律裝置蜂巢轉輪，可獲得到不減性好的低露點死板學習氣氛，內部空間劃分半打開式與全密閉式兩類；
同用于吸汗性強的工程建筑塑料材質詳細資料如 : PA、PC、PBT、PET 等 ;
集抽濕、無趣、二段給料三類作用與功效與作用于一體化，并可選擇擇幾段給料作用與功效與作用 ;
保溫隔熱式很沒意思料桶包容下電吹風管思路，配颶風改裝排氣管組裝，放置熱能工程短缺，確保安全生產溫隔熱度，進一步很沒意思物上請求權 ;
一切都電腦均混搭二次回路密閉式的送料機體系建設，可控制乏味后的材質因打架社會氣氛而首度反潮；
該題材去濕系統敞開心扉雙放涼器布置，確保安全生產更低徊風高溫及露點 ;
上料體系建設系統截料閥，確保安全生產料分液漏斗無其他材料 ;
終端服務器機械系統微我的電腦放肆為規范了機械系統，可以選擇配 PLC 放肆及 LCD 觸控式電腦網頁，調控集合的概念方便快捷，可放肆零件加工主動性使用 ;
自選配露點計，即時攝像頭監控露貼 ;
TCD dehumidification and drying combination is equipped with honeycomb wheel, can get good stability low dew point dry air, modeling is divided into semi-open and
fully closed two;
Suitable for engineering plastic raw materials with strong moisture absorption, such as PA, PC, PBT, PET, etc.
Set dehumidification, drying, two stage feeding three functions in one, and can choose three stage feeding function;
The thermal insulation drying barrel adopts the design of downblowing air pipe, with the cyclone exhaust device, to prevent the loss of heat energy, ensure the tempera?ture, improve the drying efficiency;
All machines are equipped with closed loop feeding system, can avoid dry raw materials due to contact with the outside air and damp again;
Dehumidification system adopts double cooler structure to ensure lower return air temperature and dew point;
Feeding system accessories hopper, to ensure that there is no residual raw material in the material pipe;
The machine accessories microcomputer control for the standard assembly, optional PLC control and LCD touch man-machine interface, centralized and convenient opera?tion, can control the automatic passage of the whole machine;
Optional dew point meter to monitor dew paste at any time;
